MEA INC

2600 American Lane | Elk Grove Village, IL 60007 | USA

T +1 847 766 9040 | F +1 847 350 1951

COMPLETE CONTROL

www.meaincorporated.com

MEA Incorporated | Hawk Actuator Instruction and Operation Manual

02/2018

1-3 The Hawk Actuator

The Hawk is a high-performance, rugged line of linear and rotary electro-hydraulic actuators and drives. It

is ideal for applications requiring high duty cycles, large thrust and torques, or fast stroking speeds. The

Hawk’s modular electro-hydraulic system is easily configurable to suit specific valve or damper control

requirements while at the same time providing safe and virtually maintenance free performance.

1-4 Hawk Design Features

 100% continuously modulating duty cycle

 Low installation cost - simple power & control input connection, mounting flexibility

 High-speed operation

 Complete control – low dead-band, fast response, superior linearity & repeatability

 Automatic fail-safe position and ESD functions for safety applications

 Low power consumption, motor only runs when actuator moves

 Digital control electronics

 Programmable operating parameters such as speed, position limits, acceleration, deceleration,

deadband

 Built in alarms and diagnostic features

1-4.1 Linear Actuator

 Stroke lengths up to 100”

 Thrust output up to 100,000 lbf

 Stroke speeds up to 0.2 sec/inch of travel depending on cylinder size and motor/pump selections

1-4.2 Rotary Actuator

 Rotation up to 180°

 Torque output up to 400,000 in-lbs

 Stroke speeds up to 0.5 sec/90° depending on cylinder size and motor/pump selections
