MEA Incorporated | Hawk Actuator Instruction and Operation Manual
02/2018 11
Accessories & Options
Failure Positions
Fail Last Position (Standard)
Fail Open
Fail Closed
Failure Methods
Accumulator
Spring
Emergency Shutdown (ESD) Loss of 24 VDC ESD Signal
Limit Switches
Electronic
Proximity Type, SPDT
Manual Override
Electronic HMI (Standard)
Mechanical Handwheel
Hydraulic Handpump
Performance
Speed
Adjustable from 25% to 100% of Rated HPS Speed
Resolution
0.1% of Stroke
Repeatability
0.05% of Stroke
Deadtime
80 ms
Deadband
Adjustable from 0.05% to 5% of Stroke
1-7 Area Approvals
The Hawk actuator and control enclosure must only be installed in areas which are appropriate for each
item’s respective area approval.
Actuator
Cl 1, Div 2, Groups A, B, C, D (Standard)
Cl 1, Div 1, Groups B, C, D (Optional)
Note: Carries Intertek ETL Listed Mark and is tested to CSA standards
Control Enclosure
NEMA 4X (Standard)
Cl 1, Div 2, Groups B, C, D (Optional)
Cl 1, Div 1, Groups B, C, D (Optional)
