9 [EN]
7. DRYING LAUNDRY
One of the big advantages of this dehumidifier is its ability to help you dry your laundry faster. This is thanks to its large
extraction rate, its powerful 4
th
fan speed, the swing louvre and its low running costs in Laundry Mode.
To dry laundry faster place the laundry and the dehumidifier into as small a room as possible with the doors and windows
closed so that there is less air to dry. Position the dehumidifier so that it’s dry air can hit as large an area of washing as
possible and position the clothes so that the air can circulate around them. If possible use a pedestal fan to speed up the
airflow and push more dry air across more of the washing.
Some warmth in the room will help as well.
8. AUTOMATIC DEFROSTING SYSTEM
This dehumidifier is equipped with an automatic hot-gas defrosting system. When operating in low temperatures the
surface of the evaporator will accumulate frost and this will affect the efficiency of the dehumidifier. When this
happens the machine will go into periodic defrosting automatically. Defrost time may vary. It is not recommended to
use the dehumidifier in temperatures below 5
O
C
9. ELECTRICAL CONNECTIONS
This dehumidifier was designed to operate in a 230V~50Hz electrical installation. Make sure that the electric sockets
are connected to earth and that all safety precautions are taken.
10. OPERATING CONDITIONS
This dehumidifier can be operated within an ambient temperature range from +5°C to +35°C and with a relative
humidity from 30% to 90%rh. It is suitable for applications in domestic situations and in museums and archives.
11. SPECIFICATIONS
Model
Meaco 50Lm
Temperature Range
+5 °C / +35°C
Relative Humidity Range
30% - 90%rh
Rated Voltage
220 - 240V / 50Hz
Air flow
150/170/215/280 cubic metres per hour
Tank Size
5 litres
Power Consumption
330 watts at 30°C & 80%rh
270 watts at 26.7°C & 60%rh
Refrigerant
R134a / 195g
Drying
Capacity
(L/24H)
26.7ºC – 60%rh
13.6 litres in Laundry Mode
30ºC – 80%rh
26.4 litres in Laundry Mode
Dehumidifier Dimensions (mm)
378 x 287 x 644
Box dimensions (mm)
432 x 341 x 692mm
Nett / Gross Weight (Kgs)
15.0/16.4Kgs
