Contents
 Indicator  Scale Platform
 AC120V/DC6V 500mA UL Adapter  6’ USB Cable
 Owner’s Manual  Outer Hexagonal Wrench
Load Cell Wiring
1 2 3 4
PIN1 ------ EXCITATION +
PIN2 ------ SIGNAL +
PIN3 ------ SIGNAL -
PIN4 ------ EXCITATION –
Installation
1. Remove the scale from the packaging and place it on a work table with the feet facing up. Remove the shipping
protection screw. See below pictures.
2. Place the scale on a hard, flat, and level surface
.
3. Adjust the feet to level the scale.
4. Install the batteries or plug in the adapter. Now the scale is ready for use.
