Mebay DC8-D MK Series User Manual

DC8xD MK3 GENSET CONTROLLER USER MANUAL
10
16
Speed sensor SCR
Connecting speed sensor shielded wire
ground.
1.0mm
2
17
Speed sensor +
Use a shielded wire to connect the speed
sensor.
1.0mm
2
18
Speed sensor -
1.0mm
2
19
Common GND
Connect the battery negative or outer
casing.
1.5mm
2
23
RS485 B
A 120 Ω shielded wire and good grounding
are recommended.
1.0mm
2
24
RS485 A
1.0mm
2
25
RS485 SCR
1.0mm
2
27
Aux.Output4
Passive normally closed output, Max
5Amp.
1.5mm
2
28
Aux.Output4
1.5mm
2
29
Aux.Output5
Passive normally open output, Max 5Amp.
1.5mm
2
30
Aux.Output5
1.5mm
2
31
Mains Voltage R
Connected to the mains U phase.
1.0mm
2
32
Mains Voltage S
Connected to the mains V phase.
1.0mm
2
33
Mains Voltage T
Connected to the mains W phase.
1.0mm
2
34
Mains Voltage N1
Connected to the mains N phase.
1.0mm
2
35
Generator Voltage U
Connected to the power generation output
R phase.
1.0mm
2
36
Generator Voltage V
Connected to the power generation output
S phase.
1.0mm
2
37
Generator Voltage W
Connected to the power generation output
T phase.
1.0mm
2
38
Generator Voltage N2
Connected to the power generation output
N phase.
1.0mm
2
39
Load CT Secondary L1
Current Transformer Secondary Rated 5A.
1.5mm
2
40
Load CT Secondary L2
1.5mm
2
41
Load CT Secondary L3
1.5mm
2
42
Load CT Secondary ICOM
Connect to the common GND instead of
the neutral line N.
1.5mm
2
43
Load CT Secondary ICOM
1.5mm
2
44
Temperature Sensor
Connect sensor input.
1.0mm
2
45
Oil pressure sensor
1.0mm
2
46
Fuel level sensor
1.0mm
2
47
Sensor common GND
Connect the battery negative or outer.
1.5mm
2
48
+5V Output
Connect the power supply of the oil
pressure sensor with the output voltage
signal, with a maximum of 50mA.
1.0mm
2
49
GND
Connect the battery negative.
1.0mm
2
