Mec 2633ES - Scissor Assembly - 2033 ES, Serial # 8804200 - Up

ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-5
SCISSOR ASSEMBLY - 2033ES, SERIAL # 8804200 - UP
1 17002 1 BEAM, WELDMENT
2 15077 1 BEAM, 5 × 5 × .25 W/PINS
3 17088 1 BEAM, 5 × 5 × .25 WELDMENT
4 13964 1 MAINTENANCE LOCK WELDMENT
5 17000 2 CYLINDER MOUNT
6 13931 1 BEAM, SUPPORT WELDMENT
7 17001 1 BEAM, 5 × 5 × .25 WELDMENT
8 15076 1 BEAM, 5 × 5 × .25 W/BEARINGS
9 17089 1 BEAM, 5 × 5 × .25 WELDMENT
10 HDW13175 17 WASHER, NYLON, 2.06 ID, 2.62 OD, .030 THK
11 25429 12 SPACER, RUBBER
12 6701 12 RETAINING RING, 2 INCH DIA
13 REF 1 LIFT CYLINDER (SEE FOLLOWING PAGES)
14 8675 1 BEARING, 2.25 OD × 2 ID × 1.5 LG
