October 2008 "2033ES / 2633ES" Service & Parts Manual - ANSI Specifications
Page 5-4
2033ES - Serial # 8804100 - CURRENT
2633ES - Serial # 11100600 - CURRENT
ITEM DESCRIPTION Location
CBV1 Counterbalance Valve Main manifold (MA-1)
CYL1 Steering Cylinder Machine Base, Front
CYL2 Lift Cylinder Scissor Assembly
FD1 Flow Divider Main manifold (MA-1)
FRR1 Steering Relief Flow Control Main manifold (MA-1)
HP1 Hand Pump, Brakes Brake Release Manifold (MA-2)
MA-1 Main Manifold Assembly Machine Base, Battery Compartment
MA-2 Manifold Assembly Lift Cylinder
MV1 Manifold Valve Main manifold (MA-1)
NV1 Needle Valve Main manifold (MA-1)
ORF1 Orifice Plug, Wheel Motors Main manifold (MA-1)
ORF2 Orifice Disc, Brake Release Main manifold (MA-1)
ORF3 Orifice, Down Valve Lift Cylinder Manifold (MA-3)
P1 Pump Pump Compartment
RV1 Relief Valve, Lift Relief Main manifold (MA-1)
RV2 Relief Valve, Main Relief Main manifold (MA-1)
SV1 Spool Valve, Steering Main manifold (MA-1)
SV2 Spool Valve, Lift Main manifold (MA-1)
SV3 Spool Valve, Drive Main manifold (MA-1)
SV4 Spool Valve, Brake/Decel Main manifold (MA-1)
SV5 Spool Valve, Torque Main manifold (MA-1)
SV6 Spool Valve, Torque Main manifold (MA-1)
SV9 Spool Valve, Down Lift Cylinder Manifold (MA-2)
WB1 Wheel Brake Drive Wheel
WB2 Wheel Brake Drive Wheel
WM1 Wheel Motor, Right Side Machine Base
WM2 Wheel Motor, Left Side Machine Base
