"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page 3-3
MECHANICAL COMPONENTS
Following is a description of the major mechanical components of the scissors lift.
Base / Undercarriage
When cleaning the base/undercarriage, cover electrical components
to prevent eater penetration.
Steam clean the chassis as necessary, and inspect all welds and brackets. Check for cylinder
pins that turn in their mounting, which will indicate sheared retaining pins.
Hoses and Cables
Note: Refer to
Parts Section E
for detailed hydraulic hose diagrams.
Inspect all hoses and electrical cables for security and damage. Hoses and cables should be
examined for rubbing and chafing.
Check for leaks at fittings. Replace any damaged hose or cable.
1. Tag hoses for proper reassembly.
2. Disconnect hoses and IMMEDIATELY cap the openings to prevent contamination.
3. Torque hose fittings according to the Hydraulic Torque Specification Table.
