ITEM PART NO. QTY DESCRIPTION
"2033ES / 2633ES" Service & Parts Manual - ANSI Specifications October 2008
Page C-9
SCISSOR ASSEMBLY - 2633ES, SERIAL # 11101000 -UP
1 17002 1 BEAM, WELDMENT
2 15051 1 BEAM, 5 × 5 × .188 TS W/PINS
3 15074 1 BEAM, 5 × 5 × .188 TF W/BEARINGS
4 13964 1 MAINTENANCE LOCK WELDMENT
5 17000 2 CYLINDER MOUNT
6 16585 1 BEAM, SUPPORT WELDMENT W/BEARINGS
7 17001 1 BEAM, 5 × 5 × .25 WELDMENT
8 15077 1 BEAM, 5 × 5 × .25 W/PINS
9 17004 1 BEAM, 5 × 5 × .25 WELDMENT
10 15076 1 BEAM, 5 × 5 × .25 W/BEARINGS
11 17003 1 BEAM, 5 × 5 × .25 WELDMENT
12 HDW13175 17 WASHER, NYLON, 2.06 ID, 2.62 OD, .030 THK
13 6701 12 RETAINING RING, 2 INCH DIA
14 8675 1 BEARING, 2.25 OD × 2 ID × 1.5 LG
15 REF 1 LIFT CYLINDER (SEE FOLLOWING PAGES)
16 25429 12 SPACER, RUBBER
