Page 192 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
1 83076 Control Box Cover Assembly 1
2 92199 Joystick Assembly 1
3 3772 Cover 1
4 7875 Gasket 1
5 7882 O-Ring 1
6 HDW3768 Washer, Flat 1
7 1008348 Pin, Hold Down 1
8 50155 Screw, 6–32 x 1/2 Inch 1
9 13502 Bracket, Centering 1
10 3763 Spacer, Step 1
11 13402 Gear, Large 1
12 HDW8531 Washer, Flat 2
13 HDW7881 Washer, Bevel 1
14 3782 Cam, Directional 1
15 13403 Plate, Bottom 1
16 6917 Clamp, Cable, 1/4 Inch 1
17 7818 Bearing, Bronze, Flanged 1
18 HDW3771 Washer, Flat 1
19 5736 Ring, Retaining, 1/2 Inch 1
20 50139 Screw, 4-40 x 5/8 Inch 4
21 -- -- --
22 -- -- --
23 -- -- --
24 50191 Screw, 10–32 x 1/2 Inch 12
25 3764 Plate, Spacer 2
26 8696 Switch, Limit, Micro V7 2
27 3765 Plate, Strap 2
28 3766 Plate, Top 1
29 7819 Bearing, Bronze, Flanged 1
30 8435 Spring, Joystick Centering 1
31 91824 Potentiometer Assembly 1
32 REF Wire Harness, (See Wire Harness, Section 6) 1
REF - Reference
