Page 193 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Upper Control Joystick, Early Style
ART_2221 R1
Control Arm (Joystick)Reference: ART_188
3
4
9
10
2
1
6
12
13
14
11
11
8
5
7
Connect Purple
and Blue wires
together at #13
Purple
Blue
