Page 194 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
-- 92199 Joystick Assembly --
-- 8630 Joystick Assembly Without Control Arm (#6) --
1 8750 Pin (Service Only) 1
2 8453 Switch Actuator (Service Only) 1
3 HDW8455 Screw (Service Only) 4
4 8752 Grip, Top Half (Service Only) 1
5 8751 Grip, Bottom Half (Service Only) 1
6 13638 Control Arm Without Wire 1
7 8748 Trigger (Service Only) 1
8 8456 Rocker Boot (Service Only) 1
9 8447 Switch Separator (Service Only) 1
10 8753 Motion Switch, OFF-ON (Service Only) 1
11 8448 Switch (Service Only) 2
12 91839 Amp Socket (Not Shown) 3
13 92194 Push Connector, 3/16” 1
-- 8761
Switch Assembly (Not Shown) -- Includes Item #9, Item #11 (x2), Wire And
Connectors
--
To Next Page
