Page 198 Speed Level Series - Service & Parts Manual
January 2019Section 11 - Controls
Item Part Number Description Qty.
-- 83077 Lower Control Box Assembly, ES Models 1
1 9549 Switch, 3-Position, Keyed 1
2 91667 Switch, Button, Green 2
3 7800 Switch, Emergency Stop, Red 1
4 91704 Hour Meter 1
5 91744 Charge Indicator 1
6 7235 Circuit Breaker 1
7 7423 Switch Toggle 1 Pole 2 Position 3 1
8 -- -- --
9 8082 Contact Block, N. O. 4
10 91711 Alarm, 107dB 1
11 17082 Bracket, Alarm Mount 1
12 91838 Terminal Block Module (TBM) 1
13 91659 System Controller, GP400 1
14 91887 Deutsch Connector, DRC 12 70P 1
15 90714 Contact Base 3
16 1313 Switch Guard 1
17 91290 Deutsch Connection, DT14-4P-L012 1
18 50229 Screw, 10-24 x 1.00 6
19 50230 Nut, 10-24 Nylock 6
20 50233 Screw, 8-32 x 1.00 6
21 50231 Nut, 8-32 Nylock 6
22 91921 Lanyard 1
23 92015C Control Box 1
-- REF Harness -- See Section 6 --
REF - Reference
