Page 248 Speed Level Series - Service & Parts Manual
January 2019Section 15 - Hydraulics
Item Part Number Description Qty.
1 19341 Hose Assy, 3/8” x 132”, 6G6FJX90S-6G6FJX 1
2 91265 Hose Assy, 1” x 22”, 16G16FJX-16G16FJX 1
3 19342 Hose Assy, 3/8” x 118”, 6G6FJX-6G6FJX 1
4 19369 Hose Assy, 1/4” x 28”, 4G4FJX-4G4FJX45 1
5 19370 Hose Assy, 1/4” x 33”, 4G4FJX-4G4FJX90S 1
6 19343 Hose Assy, 3/4” x 90”, 12G12FJX-12G12FJX90S 1
7 19347 Hose Assy, 3/4” x 21”, 12G12FJX-12G12FJX90S 1
8 91423 Hose Assy, 3/4” X 82”, 12M3K-12FJX-12FJX45 1
9 90276 Hose Assy, 1/4” X 24”, 4G1-4FJX-6FJX-24 1
10 50916 Fitting, MP-MJ 90 2
11 50892 Tee, MJ-FJX-MJT-4 1
12 50665 Fitting, MB-MJ-90-4-4 1
13 91163 Adapter ¾” Flange, Male 1” JIC 90 1
14 HDW91176 Adapter 1” Flange, Male 1” JIC 1
15 91161 Flange Kit #16 1
16 91162 Flange Kit #12 1
17 50660 Fitting, MB-MJ-90-6-4 1
