Page 49 Micro 26 - Service & Parts Manual
April 2019Section 17 - Chassis
Item Part Number Description Qty.
1 43554 Cover 2
2 41794 Screw 2
3 43555 Steer Yoke Weldment 1
4 43556 Bearing 4
5 43557 Washer 2
6 43558 Drive Motor Assembly 2
-- 43559 Motor 1
-- 43560 Reducer 1
-- 43561 Brake 1
7 43562 Wheel 2
8 53184 HHCS M12-1.5 × 30 Serrated Flange 10
9 43563 Cotter Pin 2
10 41321 Pin 2
11 41225 Bearing 4
12 50311 NNYL M10-1.50 Flange 2
13 50002 WSHR M10 Standard Flat 2
14 41210 Bearing 4
15 43564 Washer 1
16 41222 Bearing 2
17 43565 Tie Rod 1
18 43076 Straight Fitting 2
19 41593 Steer Cylinder Assembly 1
-- 41594 Seal Kit 1
20 50312 HHCS 3/8-16 × 1.125 Flange 12
21 43566 Steer Yoke Weldment 1
22 53194 HHCS M8-1.25 × 16 Serrated Flange 2
23 50313 NNYL M08-1.25 Flange 1
24 41425 Hose Clamp Support 1
25 43520 Hose Clamp 1
26 41415 Base Plate 1
27 50015 HHCS M08-1.25 × 50 1
To Next Page
