Page 51 Micro 26 - Service & Parts Manual
April 2019Section 17 - Chassis
Item Part Number Description Qty.
1 43567 Pothole Guard Weldment 1
2 41049 Roller 2
3 50050 NNYL M12 × 1.75 8
4 43568 Bearing 4
5 41604 Pin 4
6 43569 Pothole Hole Pusher Assembly 2
7 41222 Bearing 4
8 41210 Bearing 4
9 41807 Lock Clasp 1
10 41041 Linkage Weldment 1
11 50005 WSHR M20 Standard Flat 2
12 50052 NNYL M20 × 2.5 2
13 41808 Lock Clasp 1
14 53194 HHCS M8-1.25 × 16 Serrated Flange 4
15 41036 Limit Switch 2
16 53038 WSHR M05 Standard Flat 8
17 53171 SHCS M05-0.8 × 30 4
18 53173 SHCS M05-0.8 × 10 4
19 53043 WSHR M5 Spring Washer 4
20 41035 Switch Cover 2
21 43570 Pothole Guard Weldment 1
22 41395 Pothole Guide 1
23 50429 HHCS M10-1.50 × 25 Serrated Flange 4
24 41040 Washer 2
25 41046 Bearing 4
26 53283 Set Screw M05-0.80 × 10 Cone Point 2
27 41030 Linkage Weldment 1
28 41048 Pin 2
29 41047 Pin 2
30 41214 Bearing 4
31 43571 Pothole Link Plate 2
32 50003 WSHR M12 Standard Flat 4
33 43572 Gas Shock 2
34 43573
Gas Shock Mount 2
