Page 55 Micro 26 - Service & Parts Manual
April 2019Section 17 - Chassis
Item Part Number Description Qty.
1 43206 Elbow 2
2 43576 Straight Fitting 2
3 41077 Filter Assembly 1
-- 41078 Filter Element 1
4 53256 HHCS M06-1.00 × 16 Serrated Flange 2
5 43577 Filter Bracket 1
6 50568 NNYL M06-1.00 Flange 3
7 43578 300A Fuse Assembly 1
-- 41091 300A Fuse 1
-- 41092 Fuse Seat 1
8 53284 THMS M04-0.70 × 12 2
9 42436 Controller 1
10 43579 Screw 4
11 53281 NNYL M05-0.80 Flange 7
12 REF Hydraulic Tank Assembly (Refer To Page 56) 1
13 50313 NNYL M08-1.25 Flange 2
14 41070 Hour Meter 1
15 41068 Handle Hole Ring 1
16 53255 HHCS M06-1.00 × 20 Serrated Flange 2
17 43580 Hydraulic Tray Weldment 1
18 41067 Latch (Right) 1
19 41075 Horn 1
20 53194 HHCS M8-1.25 × 16 Serrated Flange 2
21 41074 Alarm 1
22 53071 CSCS M08-1.25 × 35 2
23 53282 CSCS M08-1.25 × 20 3
24 50561 CSCS M06-1.00 × 20 3
25 50048 NNYL M08 × 1.25 4
26 50001 WSHR M08 Standard Flat 4
27 50031 HHCS M08-1.25 × 25 4
28 43581 Motor Bracket 1
29 43582 Straight Fitting 2
30 41608 Pump Motor Assembly 1
-- 41609
Pump 1
-- 41820 Motor 1
31 41120 Bumper 1
32 53224 THMS M05-0.8 × 12 1
33 REF Motor Controller Assembly (Refer To Page 58) 1
34 41081 Function Manifold (Refer To Page 82) 1
35 53257 HHCS M08-1.25 × 20 Serrated Flange 4
36 43574 Circlips 2
37 41037 Bearing 4
38 41814 Washer 2
39 41813 Hinge Pin 2
