Page 65 Micro 26 - Service & Parts Manual
April 2019Section 17 - Chassis
Item Part Number Description Qty.
1 41098 Tilt Sensor 1
2 53173 SHCS M05-0.8 × 10 6
3 53043 WSHR M5 Spring Washer 8
4 53038 WSHR M05 Standard Flat 12
5 41829 Cover 1
6 53223 THMS M05-0.8 × 16 2
7 41309 Beacon Cover 1
8 41310 Beacon 1
9 43592 Frame Weldment 1
10 53067 SHCS M05-0.8 × 40 4
11 41036 Limit Switch 2
12 43593 Switch Bracket 1
13 53281 NNYL M05-0.80 Flange 4
14 43594 Signal Plate 1
15 50423 SHCS M04-0.7 × 12 2
16 53062 WSHR M04 Spring Washer 2
17 50284 WSHR M04 Standard Flat 2
18 50359 SHCS M05-0.8 × 16 2
19 53265 THMS M05-0.80 × 10 2
20 REF Ground Control Assembly (Refer To Page 66) 1
21 41777 Cover 1
22 53266 THMS M05-0.80 × 6 2
23 41001 Sheath 1
To Next Page
