Page 69 Micro 26 - Service & Parts Manual
April 2019Section 18 - Scissor
Item Part Number Description Qty.
1 53267 HHCS M10-1.50 × 110 Flange 2
2 43595 Cable Bridge 2
3 50022 HHCS M10-1.50 × 70 21
4 50049 NNYL M10 × 1.50 21
5 43596 Cable Bridge 2
6 43597 Circlips 15
7 REF Upper Lift Cylinder Assembly (Refer To Page 80) 1
8 41686 Pin 11
9 43598 Inner Arm 3 1
10 41688 Washer 13
11 43599 Inner Arm 2 1
12 41710 Chassis Slider 2
13 41692 Pin 2
14 41112 Hydraulic Hoses Manifolds 1
15 50386 CSCS M06-1.00 × 25 2
16 43600 Hose (To Lower Lift Cylinder) 1
17 43601 Hose (To Hydraulic Tank) 1
18 43068 Hose (To Upper Lift Cylinder) 1
19 43602 Outer Arm 1 1
20 REF Lower Lift Cylinder Assembly (Refer To Page 78) 1
21 43603 Inner Arm 1 1
22 43604 Pin 1
23 43024 Pin 1
24 53268 HHCS M10-1.50 × 30 Serrated Flange 1
25 50483 SHCS M04-0.7 × 10 2
26 50284 WSHR M04 Standard Flat 2
27 53062 WSHR M04 Spring Washer 2
28 41110 Angle Sensor 1
29 41111 Sensor Cover 1
30 41114 Block 32
31 41691 Collar 8
32 53269 CSCS M05-0.80 × 16 8
33 53270 HHCS M08-1.25 × 25 Serrated Flange 2
34 41616
Safety Arm Bushing 2
35 50313 NNYL M08-1.25 Flange 2
36 41615 Safety Arm 2
37 41687 Pin 4
38 43605 Inner Arm 4 1
39 43606 Outer Arm 2 3
40 41689 Pin 4
41 53271 HHCS M10-1.50 × 100 Flange 2
42 43607 Platform Slider 4
43 50311 NNYL M10-1.50 Flange 4
44 41685 Pin 4
45 41706 Bearing 36
46 43608 Outer Arm 4 1
47 43609 Inner Arm 5 1
To Next Page
