Page 71 Micro 26 - Service & Parts Manual
April 2019Section 19 - Platform
Item Part Number Description Qty.
1 43610 Upper Main Rail, Left 1
2 43611 Lower Main Rail, Right 1
3 43612 Upper Main Rail, Right 1
4 41357 Inserted Pin 2
5 43301 Rivet 2
6 41128 Hinge B 1
7 53273 HHCS M06-1.00 × 14 Serrated Flange 12
8 41127 Hinge A 1
9 43337 Lock Pin 2
10 43613 Door Rail 1
11 41124 Latch Handle 1
12 53272 HHCS M10-1.50 × 55 Flange 1
13 50311 NNYL M10-1.50 Flange 13
14 41125 Spring 1
15 53274 HHCS M06-1.00 × 50 Flange 6
16 50568 NNYL M06-1.00 Flange 6
17 43614 Entry Gate 1
18 43615 Main Deck Weldment 1
19 43616 Lower Main Rail, Left 1
20 53275 CSCS M08-1.25 × 45 8
21 41360 Roller Bracket 2
22 43617 Roller 2
23 41131 Bearing 2
24 43618 Circlips 2
25 53276 PHMS M04-0.70 × 8 1
26 41134 Clip 1
27 53277 BHCS M10-1.50 × 55 12
28 41059 Wire Clip 2
29 53278 SHCS M04-0.70 × 20 2
30 41120 Bumper 1
31 53224 THMS M05-0.8 × 12 1
