Page 73 Micro 26 - Service & Parts Manual
April 2019Section 19 - Platform
Item Part Number Description Qty.
1 41623 Upper Extension Rail, Left 1
2 53281 NNYL M05-0.80 Flange 1
3 43319 Manual Box 1
4 41627 Front Rail 1
5 53248 CARB M08-1.25 × 45 1
6 REF Platform Control Box Assembly (Refer To Page 76) 1
7 41764 Platform Control Box Mount Bracket 1
8 42500 Locating Plate 1
9 43453 Handle 1
10 50048 NNYL M08 × 1.25 1
11 53231 PHMS M06-1.00 × 16 4
12 53223 THMS M05-0.8 × 16 1
13 41357 Inserted Pin 2
14 43301 Rivet 2
15 53274 HHCS M06-1.00 × 50 Flange 6
16 50568 NNYL M06-1.00 Flange 6
17 53277 BHCS M10-1.50 × 55 8
18 50311 NNYL M10-1.50 Flange 8
19 41626 Lower Extension Rail, Right 1
20 43619 Extension Deck Weldment 1
21 53257 HHCS M08-1.25 × 20 Serrated Flange 2
22 41140 Platform Locking Device Assembly (Refer To Page 74) 1
23 43618 Circlips 2
24 41131 Bearing 2
25 43620 Roller 2
26 41284 Slide Pad 2
27 53279 CSCS M05-0.80 × 12 8
28 41360 Roller Bracket 2
29 53280 CSCS M08-1.25 × 55 8
30 41624 Upper Extension Rail, Right 1
31 41625 Lower Extension Rail, Left 1
32 41120 Bumper 2
33 53224 THMS M05-0.8 × 12 2
