Page 77 Micro 26 - Service & Parts Manual

April 2019Section 19 - Platform

Item Part Number Description Qty.

1 41632 Decal, Platform Control Panel 1

2 41149 Joystick 1

-- 43621 Function Enable Switch 1

-- 41150 Joystick Cover 1

-- 43622 Joystick Steer Switch 1

-- 43623 Switch Boot 1

3 41152 Coil Cord 1

-- 43624 Housing 1

-- 43625 Male Insert 1

-- 43626 Male Contacts 5

-- 43627 Cable Gland 1

4 41861 Platform Control Box Harness 1

-- 43628 Hood 1

-- 43629 Female Insert 1

-- 43630 Female Contacts 5

-- 43627 Cable Gland 2

-- 41271 Connector Kit 1

5 41568 Alarm 1

-- 43631 Alarm Nut 1

6 41156 Main Board 1

-- 41155 Button 4

7 41157 Emergency Stop Switch 1

-- 43632 Red Mushroom Head 1

-- 43633 Base With 1 NC Contact 1

8 42915 Decal, Emergency Stop Panel 1

9 43634 Enclosure 1

10 43635 Cover Bottom 1
