Mec Micro 26 - Page 91

Page 87 Micro 26 - Service & Parts Manual
April 2019Section 21 - Electrical System
Item Part Number Description Qty.
1 43713 ECU Harness 1
2 43646 Limit Switch Harness 1
3 43714 Angle Pressure Sensors Harness 1
4 41876 Communications Harness 1
5 41863 Ground Control Panel Harness 1
6 43715 Pump Motor Positive Harness 1
7 43716 Drive Motor Harness 1
8 43717 Pump Motor Negative Harness 1
9 41855 Motor Controller Harness 1
10 43718 DC Contactor Harness 1
11 43719 Battery Positive Harness 1
12 43720 Battery Negative Harness 1
13 41873 Battery Harness 1 2
14 41874 Battery Harness 2 1
15 REF Controller (Refer To Page 54) 1
16 REF Coil (Refer To Page 78) 1
17 REF Beacon (Refer To Page 64) 1
18 REF Tilt Sensor (Refer To Page 64) 1
19 REF Limit Switch, Pothole (Refer To Page 50) 2
20 REF Limit Switch, Lift Up/Lift Down (Refer To Page 64) 2
21 -- -- --
22 REF Angle Sensor (Refer To Page 68) 1
23 REF Platform Control Box Assembly (Refer To Page 76) 1
24 REF Function Manifold (Refer To Page 82) 1
25 REF Horn (Refer To Page 54) 1
26 REF Hour Meter (Refer To Page 54) 1
27 REF Brake Module (Refer To Page 58) 1
28 REF Alarm (Refer To Page 54) 1
29 REF Ground Control Assembly (Refer To Page 66) 1
30 REF Motor (Refer To Page 48) 2
31 REF Motor (Refer To Page 54) 1
32 REF Motor Controller (Refer To Page 58) 1
33 REF DC Contactor (Refer To Page 58) 1
34 REF
Fuse Assembly (Refer To Page 54) 1
35 REF Power Switch (Refer To Page 52) 1
36 REF Battery (Refer To Page 52) 4
37 REF Charger (Refer To Page 62) 1
REF - Reference
