800-797-4632 . mecoutdoors.com
4
SMART SERIES
Clay Target Machine Electrics
DISPLAY CODES
CODE/COUNTERS
DESCRIPTION
UNSAFE/LOADED
Machine is armed.
FAULT1
Motor overload, becomes a
hard fault after third attempt to
recover. (Locked Gear Box)
Replace the motor/gearbox.
FAULT2
Arm lever is cocked, but limit
switch is closed. (Mechanical
Fault)
Replace the limit switch.
FAULT7
Brake’s FET is experiencing a
short between gate and source.
Disconnect power, wait 5 seconds
or longer and then reconnect.
TROUBLE SHOOTING
CODES
SOLUTIONPROBLEM
LIFETIME COUNTER
(Push to view counter number) Displays machines life cycle target
count. This also includes every time the machine is red when a clay
target is not launched.
RESETTABLE COUNTER
Used to track usage over specic times. To reset, press and hold
selector button until the screen zeros out. Dash indicates resettable
screen.
BATTERY VOLTAGE
(Push until voltage displays) Displays the current voltage of the
battery.
Firmware Version
Displays the current Smart Electrics Firmware Version.
*NEVER USE THE SELECTOR WHEN MACHINE IS ARMED.
