2.4.5 Interface Board
a. Circuit Introduction
The interface circuit has following main functions:
(1) Provides the interface to connect SYS-6010 to peripherals, including the switching of
power supply, correspondence, drop sensor signal, bar code scanner and the external
power supply.
(2) Provides the speaker and buzzer driving circuit.
(3) Transfers the program recording signal of the power board CPU.
b. The Main Testing Points:none
c. Number and Definition of the Circuit Board Sockets
No.
Socket
PIN No.
Description
Explanation
1
J2
4
Socket to connect
speaker and buzzer
Connect speaker and buzzer
2
CON1
8
Socket to connect
power board
Connect CON1 in the power
board
3
CON2
8
Socket to connect
DC/DC power board
Connect CON2 in the DC/DC
power board
4
BUS1
5
USB2.0 socket
The interface to connect
peripherals including power
input/output, correspondence and
drop sensor; Connect MP-80
workstation, or individually
connect the external power
supply and drop sensor; Program
update of CPU in the SYS02
board.
5
BUS2
10
USB3.0 socket
The interface to connect
peripherals including power
input/output, correspondence,
drop sensor, and nurse call.
Program update of CPU in the
SYS02 board.
6
BUS3
10
USB3.0 socket
The interface to connect
peripherals including power
input/output, correspondence,
drop sensor, and nurse call.
Program update of CPU in the
power board and SYS02 board.
