6
Panel & Display
ONE TOUCH SETTING
31 M1-M4 (O.T.S.1-O.T.S.4) BUTTONS Call up the panel settings that match the current style.
32 PHRASE PAD SELECT BUTTON Enter the PHRASE PAD menu.
33 PHRASE PAD 1, 2, 3, 4 BUTTONS Start the percussion and melodic phrases playback.
34 PHRASE PAD STOP BUTTON Stop the percussion and melodic phrases playback.
35 TRANSPOSE [<], TRANSPOSE [>] BUTTONS Shift the keyboard pitch value in semitone steps.
36 OCTAVE [<], OCTAVE [>] BUTTONS Shift the keyboard pitch value in octave steps.
37 VOCAL EFFECT BUTTON Turn the microphone VOCAL EFFECT of microphone on or off.
38 PART EFFECT BUTTON Turn the keyboard PART EFFECT on or off.
39 INSERT EFFECT BUTTON Turn the voices INSERT EFFECT on or off.
40 SUSTAIN BUTTON Turn the SUSTAIN on or off.
41 MONO BUTTON Turn MONO on or off.
42 PART L, R1, R2, R3 ON/OFF BUTTONS Turn the keyboard PART L, R1, R2, R3 on or off.
43 VOICE SELECT BUTTONS Enter the VOICE SELECT interface and select voices.
44 DATA DIAL Change the value of the current selection.
45 EXIT BUTTON Exit the current menu and return to the previous display.
46 [<], [>] BUTTONS Change the value of the current selection.
47 ASSIGN 1, 2, 3 BUTTONS Turn the ASSIGN function on or off.
48 JOYSTICK Control the pitch band, modulation or assign functions of the keyboard.
49 PHONES Connect headphones.
50 51 52 53 54 55 56 57 58
59
50 POWER ON/OFF BUTTON Turn the power on or off.
51 USB TO DEVICE JACK Connect a USB storage Device.
52 USB TO HOST JACK Connect to a computer.
53 MIDI IN/OUT JACKS Connect other MIDI devices or equipment.
54 SUSTAIN PEDAL JACK Connect a sustain pedal.
55 EXPRESSION PEDAL JACK Connect an expression pedal.
56 LINE OUT JACKS Connect to external speakers or mixer.
57 AUX IN JACKS Connect external audio device to play through instrument speakers.
58 MIC IN JACK Connect a microphone.
59 AC IN Connect a standard AC 100~240V power adapter.
AKX10_OM05_EN_190816.indd 6 2019/8/16 13:37
