Setup
STEP 3: With 2 pcs hand screw fix the piano body and piano foot part
together as shown.
7
STEP 4: Use 2 PCS 4 x15 screws and gasket to fix Left/Right speakers
box, link the pedal line and speaker line according to the label,
then power it up.
STEP 2: With 4 pcs Φ6x50 "+" screws to fix the Speaker box to the ST
side boards and cover the screw caps as shown.
Speaker line connected to
on the bottom board
this socket
Speaker box line
Pedal line
