TheConnectors
4
PowerSupply
Thiselectronickeyboardcanbepoweredbycurrent
fromastandardhouseholdwalloutlet(usingthe
specifiedACadaptor).
UsingtheACadaptor
MakesurethatonlytheACadaptorspecifiedforthis
electronickeyboardisused.Theadaptorshallbe12V
DCoutput,andcenterpositivetype.
Besuretoturnofftheelectronickeyboardbeforeyou
connecttheadaptorintotheACwalloutletandthe
cordintotheunit.
UseonlythespecifiedACadaptor.Useofanother
typeofadaptorcreatesadangeroffireandelectrical
shock.
Forsafetysake,ensuretounplugtheACadaptor
fromthewalloutletwheneverleavingtheelectronic
keyboardunattendedforalongtime.
DC12V
CAUTIONS!
Apairofstereoheadphonescanbepluggedintothe
PHONESjackforprivatepracticeorlatenightplaying.
Theinternalspeakersystemisautomaticallyturnedoff
whentheheadphonesispluggedintothePHONES
jack.
Anoptionalfootswitchcanbepluggedintothe
SUSTAINjackforvariouspedalfunctions.
Fordetailspleaseseethesection"FunctionSelect"
inthismanual.
Theheadphonejack
DC12VPHONES
AUX
OUT
SUSTAINMIDIOUTMIDIIN VOLUME
TheSustainjack
DC12VPHONES
AUX
OUT
SUSTAINMIDIOUTMIDIIN VOLUME
TheAUX.OUTjackdeliverstheoutputofthekeyboard
forconnectiontoanexternalamplifier.
Usinganaudiocord,plugintoAUX.OUTjacklocated
ontherearpanel.Thenplugtheotherendofthe
cordintoLINEINorAUX.INoftheamplifier.
TheAux.Outjack
Stereo
System
DC9~12VPHONES
AUX
OUT
SUSTAINMIDIOUTMIDIIN VOLUME
