User manual for medifa 5000 operating table Version 2.1
We recommend connecting a potential equalisa-
tion cable whenever the operating table is used.
Connect the potential equalisation pin [1] with
the potential equalisation line to the potential
equalisation of the operating room. (This must be
done according to VDE-0107 or the corresponding
national regulations).
Figure 6: Potential equalisation pin
12.6 Connection of the potential equalisation cable
Initial commissioning
12.5 Removing split leg plates
1. Hold the leg plate and turn the release lever on
the table upward.
2. Pull the leg plate out of the square openings on
the table.
