User manual for medifa 5000 operating table Version 2.1
Figure 11: Backrest adjustment
When adjusting the back, the back plate is tilted up or down with the head rest.
By pulling the lever [1] towards the head end, the springs are released and by slightly lifting or lowering the back
plate at the head rest section end, the adjustments are made. Releasing the lever locks the backrest position.
Adjustment range: -40° to +70°
CAUTION
Risk of injury!
Operation with both hands is absolutely necessary for safety reasons, since the operator must exert his/her
own body strength for adjustment, depending on the patient’s body weight!
Positioning of patient
13.6 Backrest adjustment
