User manual for medifa 5000 operating table Version 2.1
Positioning of patient
Figure 12: Operation shackle
13.7 Triggering the driveability
The driving situation is controlled via the operation
shackle [1].
Upper position - operating table is di-
rectionally stable because the foot-side
castors are directed straight ahead.
Middle position - operating table can be
moved in all directions as all castors are
freely movable.
Lower position - brake is put on the
operating table.
