Medisoft Ergocard CPX - Front Panel

H4-EN General overview P
AGE 17/44
3
3.2 Front panel
Front panel
Power LED
Flow measurement port
Sample line port
Calibration port (connector for umbilical during calibration)
Connector for NONIN oximeter (SpO
2
)
Umbilical
Prevent flow sensor
Extension for NONIN oximetry sensor
NONIN oximetry finger sensor
j
i
h
g
f
e
d
c
b
a
