4.2 Rear panel connections
Power supply cable
USB cable (connected to computer)
Serial cable (connected to treadmill, bicycle, …)
Gas supply tube (connected to gas tank 21% O
2
– balance N
2
)
Gas supply tube (connected to gas tank 16% O
2
– 4% CO
2
– balance N
2
)
e
d
c
b
a
