3.2 Rear Side
3.3 Technical Data
Dimensions (L/W/H) in mm Other
Thermal Unit 360 x 600 x 340 Weight 20 kg
Prewarming Chamber 300 x 210 x 115 Protection Type IP 20
Inner Warming Tray 290 x 235 x 45
Outer Warming Tray 310 x 270 x 48 Model 115V
Power Supply 115V / 60Hz / 750VA
Temperature Fuse T6.3A
Prewarming Chamber 30 °C – 70 °C
Warming Tray 30 °C – 75 °C Model 230V
Power Supply 230V / 50Hz / 750VA
Fuse T3.15A
(1)
(1) Main switch (O – OFF / I – ON)
(2) Connection socket for main cable with safety switch
(2)
figure 6
Please check the type plate for power supply and fuse! The values need to match your
local conditions (power supply).
