Slit Lamp Microscope USER MANUAL
13 / 29
11 Magnification changer
Five different magnifications are provided
12 Binocular tubes base
Open it to both sides and adjust to the appropriate distance for easy observation
13 12.5X Eyepieces
14 Yellow filter rod
Pull up or press to switch the yellow filter
15 Slit movement platform
Moving up and down to makes the slit opening and closing, and the lower scale shows
the angle between the slit and the vertical direction.
16 Slit height control knob
Rotate this knob to adjust the spot and the slit height. Swing the knob horizontally to
revolve the slit
17 Filter selection lever and display mark
The lever can choose different filters
18 Aperture slit height and display window
It will display the diameter of the slit and the aperture.
19 Lamp cap
With the function of protecting and insulating, its normal working temperature is around
51℃
20 Power plug
21 Where the light source component power is connected ,The Fixation Knob of Lamp
Cap.
After fixing the knob, the lamp cap will not move
22 Headrest belt
To fix the patient’s head on an appropriate position
23 Fixation target
Make the patient stare at it, it is convenient for checking
24 Chin-rest paper fixing bolt
For fixing the pad paper
25 Chin-rest
Supporting the patient’s chin
26 Focusing testing rod
27 Chin-rest Elevation Adjustment Knob
Rotate the knob to adjust the elevation of the chin-rest
28 Illumination arm locking knob
When the knob is tightened, the illumination system and the observation system are in a
linked state and can rotate together. When the knob is loosened, the illumination system
can be rotated separately.
29 Microscope arm locking knob
