BarMaster
Connecon
The BarMaster is connected in line with the controller’s 24V power supply
cable. The power cable is connected to the BarMaster and, in turn, its cable is
connected to the 233v4 controller.
Note: The Meech BarMaster does not come with the 233v4 and must be
purchased separately.
WARNING
It is recommended to turn-o󰀨 the 24V power supply to the controller and wait a few
seconds before disconnecting the power cable from the controller. Failure to do so
will not damage the equipment, but may result in a small shock caused by the stored
energy in the ionising system.
 Aach the cable on the BarMaster to the M8 connector on the
controller, then connect the M8 connector from the power supply to
the BarMaster.
 Switch on the power supply. Aer a few seconds, the BarMaster will
establish a connecon to the controller and display the controller’s
sengs and status.
