Page #29 background image
29
Technical Construcon
Supply Voltage 24V DC
Input Connecon 4 Pin M8 Connector
Output Voltage
2-15kV Pulsed DC, adjustable with
BarMaster
Number of Outputs 4 (2 Posive, 2 Negave)
Output Frequency
Adjustable with BarMaster or
SmartControl Touch from 1-20Hz
Output Balance
Adjustable with BarMaster or
SmartControl Touch from 80:20 to
20:80 Pos:Neg
Output Current 600 µA Maximum
Output Short Circuit Limit 5mA
Electrical Consumpon Maximum 625 mA
Operang Environment 0-55°C
LED Indicaon Red/Green/Amber LED
Protecon Class IP67
Remote HT on/o
3-pin M8 Connector (blue and
brown wires used)
Clean Pin and Fault Alert 0/24V
Dimensions (mm) 46 x 93 x 129
Weight 650g
Housing Material DuraForm PA (Nylon 12)
