12
Dual Alarm Alert - Remote Monitoring
Remote monitoring of the need to clean the bar is provided by the output signal on
pin 2 (white) and fault alert is provided on pin 4 (black). The signal is 0V-24V suitable
for direct connection to a PLC input. The output impedance of the signal is 10kΩ. The
output can also be congured to power an external relay to provide volt-free contacts
for other monitoring systems.
Using a BarMaster remote programmer or SmartControl the output can be set
to Alarm True = Lo (Normally Open) which is factory default or Alarm True = Hi
(Normally Closed).
NOTE: Make sure that BarMaster is not connected when using the dual alarm
remote monitoring feature.
Alarm Pins
Pin-2 (White) This pin is used to report when the HV output of the equipment
needs cleaning. This is considered as a warning signal. The LED
pattern on the unit is ashing red.
Pin-4 (Black) This pin is used to report when the HV output of the equipment is
critically low. This is considered as a serious fault. The LED pattern
on the unit is solid red.
