Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installations and electron-
ics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots(ceiling, suspension, trussing).
3) Mechanically moved parts like axles, eyes and other must not show any traces of wearing and must not rotate with unbal-
ances.
4) The electronic power supply cables must not show any damages, material fatigue(e.g. porous cables) or sediments. Further
instructions depending on the installation spot and usage have to be adhered by a skilled installer and any safety problems
have to be removed.
Disconnect from mains before starting maintenance operation!
Caution Danger to life!
We recommend a frequent cleaning of the device. Please use a moist, lint free cloth. Never use alcohol or sol-
vents!
1) The objective lens will require periodic cleaning on usage and environment. Environment with foggers will require more peri-
odic cleaning as fog fluid tends to build up residues, reducing the light output.
2) The cooling-fans should be cleaned monthly. DO NOT blow high pressure air into fans as incorrect rotation can damage the
fans operation.
3) The gobos, dichroic color filters and internal lenses may be cleaned with soft brush using soapy water.
4) The interior of the fixture should be cleaned using a vacuum.
5) We recommend proper lubrication of the gobo wheel. The quantity of the oil must not be excessive in order to avoid oil run
Note: There is no serviceable parts inside the device except for the lamp anf the fuse. Maintenance and service operations are
to be carried out by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by authorized dealers only
In order to avoid hazards.
Should you have further questions , please contact your dealer.
17
Parts List
P-1010PCB Main PCB Card
P-1010DC-AB Driver Card
P-1010DC-DC Driver Card
P-1010DIS Display Card
P-1010case Dual Axis 500 Case
P-1010FAN-S Lamp Fan 1.5X1.5
P-1010IG Igniter
P-1010PRISM Prism
P-1010R-SET Quick Release Mount Set
P-1010FAN Fan 3X3
P-1010RF Reflector
LMSD575 Phillips MSD 575
LNSK575 NSK 575
P-1010IRF IR Filter
P-1010FLS Full Lens Set
LMSR575/2 Phillips MSR 575/2
P-1010FPBS Full Plastic Body Set
P-1010CWM Color Wheel Motor
P-1010FCW 1Color Wheel
P-1010RPST Power Supply Transformer
P-1010FGS Full Gobo Set
P-1010CSPCB Color Sensor PCB
