Axis 500 DMX profile-version 1.0
8
DMX Channel Function Description Value
1 Pan Pan course 0-255
2 Tilt Tilt course 0-255
3 Pan Fine Pan fine 0-255
4 Tilt Fine Tilt fine 0-255
5
0
1-249
250-252
253-255
Max speed (tracking mode)
Max to min speed (vector mode)
Changes
Changes with pan and tilt movement
Speed
0-127
128-139
230-239
Fan speed from fast to slow
Lamp on
Lamp off (hold 3 seconds)
Control
6
0
13
0-255
194-255
128-190
115
102
90
77
64
51
38
26
Open
Color macros if channel 8 set between 128-255
Backward rainbow effect fast to slow
Forward rainbow effect fast to slow
Orange
Green
Cyan
Magenta
Yellow
Light Green
Blue
Red
Light blue
Color 1
(Bi-color beam if set
between color)
7
0-11
128-255
120-127
108-119
96-107
84-95
72-83
60-71
48-59
36-47
24-35
12-23
Enable macro color function on Channel 7
Open
UV filter
3200K filter
6000K filter
Yellow
Magenta
Cyan
Pink
Deep Blue
Deep red
Open
Color 2
(Snap color wheel)
8
0
1-63
64
65-127
Open
Forward rotation from fast to slow
No rotation
Backward rotation from slow to fast
Prism
9
Prism gobo macro1 128-135
Prism gobo macro 2 136-143
Prism gobo macro 3 144-151
Prism gobo macro 4 152-159
