Mega System Technologies NetAgentA - Chapter 2. NetAgentA Series; 2.1 NetAgentA Mini Models; 2.2 NetAgentA Mini LED Indication

Chapter 2. NetAgentA Series
2.1 NetAgentA Mini Models
2.2 NetAgentA Mini LED Indication
Status LED
RJ45 Ethernet
NOTE : When writing firmware, red led alternating flashing, DO NOT remove any power
NetAgentA Mini Model
Model Name Package Contents
Internal External RJ45 RS232 ENV USB Single
Phase
Three
Phase
DA520
1. NetAgentAA Mini SNMP Card
2. NetAgentA Utility CD
3.
Quick Installation Guide (Optional)
v
v v v
DA806
1. NetAgentAA Mini SNMP Card
2. NetAgentA Utility CD
3. Quick Installation Guide (Optional)
4. M2509 Cable (USB)
v
v v v v
DA807
1. NetAgentAA Mini SNMP Card
2. NetAgentA Utility CD
3. Quick Installation Guide (Optional)
v
v v v v
Amber
Red
Communication
Connection Status with UPS
Flashing
Flashing
Off
Transferring data with UPS
Lost
connection
Connecting
with UPS
Green
Yellow
Power Status
NetAgent
A
Mini Status
On
Off
On
Off
Normal No Power Operating Stop working
Green
On Flashing
100
Mbps
Sending/
Receiving
Data
Yellow
On Flashing
10
Mbps
Sending/
Receiving
Data
When Green and Yellow LED are both ON,
it runs at 1000M mode
