7
Bolt the extractor to the end of the shaft.
(Using pressure, turn one half turn).
Sometimes, tapping the extractor gently with a
hammer can help free the shaft of the drive
pulley from the flywheel.
Turn the bolt of the extractor until the pulley
pulls away from the shaft of the flywheel (1).
, Once you’ve removed the drive pulley, make sure
the drive belt can rotate in the same direction
as before you removed it.
Driven pulley
extractor
