6
Removing the Pulleys from the Vehicle
Remove the bolt (5) from the drive pulley and
the bolt (9) from the driven pulley.
Removing the Drive Pulley
Remove the nut that holds the drive pulley in a closed position.
(use a 30mm bushing)
, Make sure you don’t drop the cap and the
units.
(It’s safer to remove the free parts, that is,
the parts that are no longer attached.)
Use an extractor that is appropriate for the threads at the end of the shaft (20 mm or ¾ inch).
Insert the extractor rod into the shaft of the
drive pulley.
