19
The stationary sheaf (1) cannot be disassembled without damaging the parts. All you can
do is inspect it.
Inspection
• Wear damage to the shaft (inside and out)
• Wear to the sheaf’s working angle
• Visual inspection
Reassembling the Driven Pulley
Mounting the cam fittings on the sliding sheaf
Use a hammer to mount the cam fittings (4A).
, Don’t be too rough with the hammer. You might damage the fittings.
