Reinstalling the Pulleys on the Vehicle
Once the pulleys and the drive belt are properly installed, use a torque wrench
(standard torque) to tighten the two bolts.
Minimum
diameter of
the bolt
Grade Standard torque
(newton meter)
8 mm 8.8 21 to 28
10 mm 8.8 42 to 54
To tighten the drive pulley, use a screwdriver or other tool to block the engine
from turning. Be careful not to damage any of the parts.
