8
Removing the Driven Pulley
The driven pulley can be removed manually but, in some cases, using the driven pulley
extractor can help.
Inspecting the Drive Belt
L ,The drive belt has to be inspected to avoid damage that might cause
bodily harm and/or material damage.
• The drive belt must be replaced if you can see cracks in it when it’s turned inside out.
The drive belt has an original width that allows the transmission system to work properly.
It must be replaced according to the specifications in the table below:
Number starting with Original width Width at which to replace
B32-------- 29 mm 27mm
D32-------- 33 mm 31mm
