4) Connect the power cord of the equipment (control unit) to a main
source with voltage compatible with the specifications of the hipot (200-
240 V, 50/60 Hz).
5) Make sure all connections are correct and release the generation lock
button on the high voltage unit, allowing the system to work.
Basic diagram of connection of the cables in the control unit, high voltage and
in the element to be tested.
