DLRO10 and DLRO10X
22
10. ACCESSORIES
Standard Accessories supplied with all instrument.
Battery DLRO10/10X 5.2 Ah 6121-492
User guide DLRO10/10X 6172-681
Warranty / Cert of Test [1 YEAR] MEGGER 2000-231
Test leads supplied with instruments
DLRO10-NLS Ducter Ohmmeter NO LEAD SET 1006-660
DLRO10X-NLS Ducter Ohmmeter NO LEAD SET 1006-659
DLRO10 Ducter Ohmmeter + DH4-C 1006-598
DLRO10X Ducter Ohmmeter + DH4-C 1006-600
DH4-C Connect Duplex Handspike 1.5m (x2) 1006-444
Optional Accessories at extra cost
Carrying Case for DLRO10/10X + all accessories 6380-138
Calibration Shunt , 10 Ω, current rating 1 mA 249000
Calibration Shunt resistor, 1 Ω, current rating 10 mA 249001
Calibration Shunt resistor, 100 mΩ, current rating 1A 249002
Calibration Shunt resistor, 10 mΩ, current rating 10 A 249003
Calibration certificate CERT-NIST
Replacement tips for DH4 handspikes.
Needle point 1008-024
Waffle end 1010-929
DLRO10LPU-EU Mains Line Power Unit - SCHUKO plug 1003-172
DLRO10LPU-UK Mains Line Power Unit - UK plug 1003-093
DLRO10LPU-US Mains Line Power Unit - US plug 1003-171
DLRO10LPU line power unit
The DLRO10 and DLRO10X may be also powered from an optional
mains / line power supply unit the DLRO10LPU. This unit is simply fitted
to the instrument in place of the standard battery pack.
When in use a red LED is illuminated when the instrument is powered
from a mains / line power supply. The DLRO10X is seen here fitted with
the optional DLRO10LPU. Ideal for repetitive testing applications such as
manufacturing production line use
Optional Test Leads at extra cost Duplex Leads Normal test
leads not fitted with inline connector:
DH4-C Connect Duplex Handspike 1.5m (x2) 1006-444
DH5 straight duplex handspikes (2). One has indicator lights.
2.5 m/8 ft 6111-517
DH6 Duplex handspikes (2) suitable for working on 600 V. systems.
2.5 m/8 ft 6111-518
Duplex Handspikes (2)with spring loaded helical contacts.
2 m/7 ft 242011-7
2.5 m/8 ft 6111-022
5.5 m/18 ft 242011-18
6 m/20 ft 6111-023
9 m/30 ft 6111-024
Straight Duplex Handspikes (2) Heavy Duty with fixed contacts.
2 m/7 ft 242002-7
5.5 m/18 ft 242002-18
9 m/30 ft 242002-30

Megger DLRO10 Specifications

General

Resolution	0.1 µΩ
Protection	IP54
Test Current	10 A
Resistance Range	0.1 µΩ to 2000 Ω
Display	LCD
Power Supply	Rechargeable battery
Operating Modes	Normal, Auto, Continuous
Accuracy	±0.2%
