5
CAT II - Measurement category II: Equipment connected between the electrical outlets and the user’s equipment.
CAT III - Measurement category III: Equipment connected between the distribution panel and the electrical outlets.
CAT IV - Measurement category IV: Equipment connected between the origin of the low-voltage mains supply and the distribution panel.
1.1 Symbols used on the instrument
G
Caution: Refer to accompanying notes
t
Equipment protected throughout by Double or reinforced Insulation (Class II)
Equipment complies with current UKCA directives
c
Equipment complies with current EU Directives
Do not dispose of in the normal waste stream

Megger DLRO10 Specifications

General

Resolution	0.1 µΩ
Protection	IP54
Test Current	10 A
Resistance Range	0.1 µΩ to 2000 Ω
Display	LCD
Power Supply	Rechargeable battery
Operating Modes	Normal, Auto, Continuous
Accuracy	±0.2%
