Dimensions 220 x 92 x 50 mm (8.66 in x 3.63 in x 1.97 in)
Weight 590 gms, 775 gms with boot (20.73 oz
(27.22 oz)
Fuse
Use only a 500 mA (FF) 1000 V 32 x 6 mm ceramic fuse of high
breaking capacity HBC 50 kA minimum. Glass fuses MUST NOT be
fitted.
Safety Protection
The instruments meet EN 61010-1 (1995) to 600 V phase to earth,
Category IV.
Refer to safety warnings (see section 2).
E.M.C.
In accordance with IEC 61326 including amendment No.1
Temperature effects
Temperature coefficient <0,1% per °C up to 1 GΩ
<0,1% per °C per GΩ above 1 GΩ
Environmental
Operating range: -20 °C to +55 °C
Operating humidity: 95% RH at 0 ºC to +35 °C, 70% RH
+35 °C to +55 °C
Storage temperature range: -30 °C to +80 °C
Calibration Temperature: +20 °C
Maximum altitude: 2000 m
Dust and water protection: IP54
